Uncooled thermal rifle scope OLED (1440*1080) display With Picatinny rail Motio
Reliable shipping
Flexible returns
Features:
· 384*288 pixels
· OLED (1440*1080), A High-performance display
· 1000m accurate laser distance measurement
· Equipped with electronic compass and motion sensors
· Compact and lightweight, easy to carry around.
· Multiple cross-hatching and customizable memory calibration parameters can be set.
· With the latest Lison II detail enhancement algorithm for a clearer picture
· WiFi transmission of images and built-in video and photo functions.
· Protection class IP66, weatherproof
· Available with universal Pica tinny rail.
Technical specification:
Item number |
BGRS519-384 |
|
|
Detector |
|
||
Pixel |
384x288 |
|
|
Pixel spacing |
12 μm |
|
|
Wavelength range |
8-14 μm |
|
|
NETD |
<=35mk |
|
|
IR lens |
|
||
Focus |
19mm/F1.0 |
|
|
Field of view |
13.8’’x10.4’’ |
|
|
Focusing method |
Manual |
|
|
Monitor |
OLED, 0.39’’, 1440*1080 |
|
|
Image display |
|
||
Eyepiece Parameter |
40mm |
|
|
Magnification |
1.77x-7.08x |
|
|
Diopter Adjustment |
-5D-+5D |
|
|
Laser rangefinder |
Can be extended (optional), ranging from 10-1000m |
|
|
Electronic compass/motion sensor |
Support |
|
|
Wi-Fi |
Support |
|
|
Image performance |
|
||
Frame rate |
50Hz |
|
|
Image correction |
Auto/manual |
|
|
E-zoom |
2x, 4x |
|
|
Hot-spot tracking |
Support |
|
|
Cross reticle |
Support |
|
|
Palette |
White heat, black heat, iron red, red heat, forests. |
|
|
Image transmission |
WiFi real-time image transmission, photography, and video |
|
|
Image Storage |
|
||
Memory |
32GB |
|
|
Photos |
Support |
|
|
Video |
Support |
|
|
Power system |
|
||
Battery type |
Single standard 26500 rechargeable lithium battery, replaceable |
|
|
Battery working time |
>5 hours |
|
|
Charging method |
Support online charging |
|
|
External power supply |
DC5V/2A |
|
|
Interface |
|
||
Date interface |
Type-c |
|
|
Installation interface |
Three standard fixing screw holes, and different optional mounting brackets |
|
|
Physical characteristic |
|
||
Dimension(mm) |
165*80*65mm |
|
|
Weight(g) |
470g |
|
|
Environment parameter |
|
||
Working temperature |
-30°C-+55°C (-22°F - 130°F) |
|
|
|
|||
Storage temperature |
-40°C --- 70°C |
||
Mmax. Recoil Power |
800g/ms |
||
Capsulation |
IP66 |
||
Detection distance | |||
Human(1.8x0.5)m |
750m |
||
Car(2.3x2.3)m |
1800m |
||
Recognition distance | |||
Human(1.8x0.5)m |
376m |
||
Car(2.3x2.3)m |
910m |
||
